SGS Plain Weave 8X8 Stainless Woven Wire Mesh

  • 1
  • 2
  • 3

Brand Name : R&K

Model Number : SS-16

Certification : SGS

Place of Origin : Hebei

MOQ : 1 squaremeter

Price : Negotiate

Payment Terms : L/C, D/P, T/T, Western Union，PayPal

Supply Ability : 1000 squaremeter per week

Delivery Time : 5-8 workday

Packaging Details : inside with paper tube,Then waterproof paper covered,Finally in a wooden case or pallet

Name : SGS Plain Weave Stainless Steel Wire Mesh Filter Mesh Used For Chemical Fiber Industry

Usage : Chemical Fiber Industry

Weave style : Plain weave

Color : Silver

Advantage : High strength

Hole shape : Square hole

Contact Now

SGS Plain Weave Stainless Steel Wire Mesh Filter Mesh Used For Chemical Fiber Industry

Descriptions of the mesh:

According to the type of weaving, HEBEI REKING WIRE MESH CO.,LTD'S stainless steel wire mesh can be divided into stainless steel wire mesh opening and Dutch wire mesh Dutch weaving, while square opening stainless steel wire mesh can be further divided into square mesh plain weave and square mesh twill weave .

Stainless steel wire mesh square openings are commonly referred to as woven stainless steel wire meshes with plain weave or twill weave patterns.

Technical Description:

Standard width stainless steel wire mesh: 1 or 48 inches; an additional 4m roll width stainless steel wire mesh can also be provided.

The standard roll length is 30 m or 100' stainless steel wire mesh.

Plain weave description:
Plain weave is a commonly used weaving method. Determine the warp, the length of the screen and the weft so that they are parallel to the width, intersect each other, alternate at the top and below, forming a 90° angle to each other.
The solid woven wire mesh may have square or rectangular openings.

Plain mesh clothing is a basic part of the production of filters, food colanders, chemicals, protective covers, mosquito nets, etc.

Feature of stainless steel mesh

For the stainless steel wire mesh , can used be for filter, and also can be cutted for small pieces,like round, square shape.Then used for the part of the machine.

Application of the mesh:

SGS Plain Weave Stainless Steel Wire Mesh Filter Mesh is used for screening and filtering in acidic or alkaline environments. It is used as a mud net in the petroleum industry, a chemical net in a chemical filling net, a screen in the chemical fiber industry, and a pickling net in the electroplating industry.

Parameter of stainless steel mesh

mesh Wire Diameter Aperture Open Area Weight
Inch MM Inch MM (%) (kg /Square meter)
1x1 0.08 2.03 0.92 23.37 92 2
2X2 0.063 1.6 0.437 11.1 87.4 2.5
3X3 0.054 1.37 0.279 7.09 83.8 2.7
4X4 0.047 1.19 0.203 5.16 81.2 2.7
5X5 0.041 1.04 0.159 4.04 79.5 2.6
8X8 0.02 0.5 0.105 2.675 71 1
9X9 0.02 0.5 0.091 2.32 67.7 1.1
10X10 0.025 0.64 0.075 1.91 74.9 2
12X12 0.02 0.508 0.063 1.6 75.9 1.5
12X12 0.022 0.55 0.062 1.567 54.8 1.815
14X14 0.02 0.508 0.051 1.3 71.9 1.8
14X14 0.0177 0.45 0.054 1.36 75.14 1.417
16X16 0.016 0.4 0.047 1.188 55 1.28
16X16 0.018 0.457 0.0445 1.13 71.2 1.6
18X18 0.017 0.432 0.0386 0.98 69.4 1.6
20X20 0.02 0.24 0.03 0.76 76 0.56
20X20 0.016 0.33 0.034 0.86 72.2 1.1
20X20 0.014 0.35 0.036 0.92 52.5 1.225
20X20 0.016 0.4 0.034 0.87 46.9 1.6
20X20 0.0177 0.45 0.0322 0.82 41.7 2.025
22X22 0.012 0.3 0.034 0.854 54.76 0.99
24X24 0.014 0.35 0.028 0.708 44.77 1.47
30X30 0.014 0.35 0.0195 0.5 34.6 1.84
30X30 0.012 0.305 0.0213 0.54 63.9 1.4
30X30 0.0094 0.24 0.0243 0.62 72.1 0.84
35X35 0.0079 0.2 0.021 0.526 52.5 0.7
35X35 0.0098 0.25 0.0187 0.475 42.92 1.09
40X40 0.0079 0.2 0.017 0.435 46.9 0.8
40X40 0.01 0.254 0.015 0.38 59.9 1.3
40X40 0.014 0.35 0.011 0.285 20.14 2.45
50X50 0.0055 0.14 0.0145 0.368 72.4 0.48
50X50 0.0079 0.2 0.012 0.308 36.76 1
60X60 0.0047 0.12 0.012 0.303 71.6 0.42
60X60 0.0059 0.15 0.0107 0.273 64.5 0.65
60X60 0.007 0.18 0.0096 0.243 33 0.972
80X80 0.047 0.12 0.0078 0.1975 38.7 0.576
80X80 0.0055 0.14 0.0069 0.117 45.5 0.76
100X100 0.0039 0.1 0.006 0.154 36.76 0.5
100X100 0.0045 0.114 0.0055 0.14 55.1 0.59
100X100 0.004 0.102 0.006 0.152 59.8 0.49
120X120 0.0028 0.07 0.0057 0.147 67.7 0.29
120X120 0.003 0.08 0.0052 0.132 38.7 0.384
150X150 0.0024 0.06 0.0043 0.11 64.7 0.26
150X150 0.0028 0.07 0.0039 0.1 58.8 0.38
165X165 0.0019 0.05 0.0041 0.104 67.5 0.2
180X180 0.0019 0.05 0.0035 0.091 64.5 0.22
180X180 0.0024 0.06 0.0031 0.081 57.4 0.32
200X200 0.0019 0.05 0.003 0.077 60.6 0.24
200X200 0.0024 0.06 0.0026 0.067 52.7 0.35
250X250 0.0016 0.04 0.0024 0.0616 60.6 0.2
270X270 0.0016 0.04 0.0021 0.054 57.4 0.21
300X300 0.0016 0.04 0.0018 0.045 53.5 0.23
325X325 0.0014 0.035 0.0017 0.0432 55.3 0.2
400X400 0.0012 0.03 0.0013 0.0335 52.7 0.18
500X500 0.0009 0.025 0.001 0.0258 50.7 0.15
500X500 0.0012 0.03 0.0008 0.0208 16.76 0.225
635X635 0.0007 0.018 0.0008 0.022 55 0.1
